Aries Round

Aries Round is equipped with impressive sized stone space and fast heating capability. It is most suitable for small and medium-sized sauna rooms.

Timer and thermostat controls of all Aries models can switch sides. This allows more flexibility for heater location.

Power rating from 4.5 kW up to 18 kW

Technical Data

Heater Model	KW	Sauna Room min (m3) max	Control	Size of heater (mm) WIDTH DEPTH HEIGHT	Stone (kG)
ARI3-45NB	4,5	3 – 6	8+4h	300 – 300 – 930	60
ARI3-60NB	6	5 – 9	8+4h	300 – 300 – 930	60
ARI3-75NB	7,5	7 – 13	8+4h	300 – 300 – 930	60
ARI3-90NB	9	8 – 14	8+4h	300 – 300 – 930	60
ARI3-45NS	4,5	3 – 6	separate	300 – 300 – 930	60
ARI3-60NS	6	5 – 9	separate	300 – 300 – 930	60
ARI3-75NS	7,5	7 – 13	separate	300 – 300 – 930	60
ARI3-90NS	9	8 – 14	separate	300 – 300 – 930	60
ARI6-90NB	9	8 – 14	8+4h	440 – 440 – 930	110
ARI6-90NS	9	8 – 14	separate	440- 440 – 930	110
ARI6-105NS	10,5	9 – 15	separate	440 – 440 – 930	110
ARI6-120NS	12	10 – 18	separate	440 – 440 – 930	110
ARI6-150NS	15	13 – 23	separate	440 – 440 – 930	110
ARI6-180NS	18	15 – 26	separate	440 – 440 – 930	110

Ni2 Heater

Heater Model	KW	Sauna Room min (m3) max	Control	Size of heater (mm) WIDTH DEPTH HEIGHT	Stone (kG)
ARI3-45Ni2	4,5	3 – 6	Saunova 2.0	300 – 300 – 930	60
ARI3-60Ni2	6	5 – 9	Saunova 2.0	300 – 300 – 930	60
ARI3-75Ni2	7,5	7 – 13	Saunova 2.0	300 – 300 – 930	60
ARI3-90Ni2	9	8 – 14	Saunova 2.0	300 – 300 – 930	60
